We are offering Universal Truck Tyre Changer "Large" version changer may mount and demount all kind of large buses with various model of tyres. It is also applied to tyres with split ring, radialply tubeless (without inner tube) and other agricultural and engineering tyres.

Features:
*Apply to the rim dimension between 14"-26"
*Lifting arm and universal chuck are all driven by the hydraulic pressure.
*Locking jaws with different gripping possibilities.
*Movable low-voltage control unit.
*Operating Voltage 24V, Safety and stable.

Technical Specification:

Rim Diameter : 14"-26"
Max. Wheel Weight : 500kg
Max wheel width : 780mm
Max tyre diameter : 1600mm
Hydraulic Pump Motor : 1.5kw 380V-3PH
Gear box motor : 1.5kw, 380V-3PH
Operating Pressure : 0-130bar
Bead Breaker Force : 1500kg
Operation control voltage : 24V
Net Weight (Approx) : 518kg
Overall Dimensions (Approx) : 2500x2000mm
